Functional use:
Automatic classification, statistics, data storage and packing according to the set weight level, and the weight range can be up to 18 zones.
According to the customer's production technology professional design customized front-end and back-end, different feeding modes for different industries by grading device
Flexible integration with the existing production line, do not need to change the production line
Sorting faster and more reliable, the labor cost will be reduced to improve production efficiency
Mainly used for classification of a variety of fresh frozen water seafood, poultry meat food processing, automobile hydraulic hardware accessories, daily necessities, weight sorting and packing etc. and many other fields.
Main features:
The design of custom feeding, parallel, shaping, chamfering, weighing and sorting the entire production line
Reinforced stainless steel frame, comprehensive waterproof design, available water directly
Using high precision sensor, advanced digital signal processing technology
Dynamic weight automatic compensation technology, automatic zero point analysis and tracking technology
Can be customized according to customer specific application requirements of the weight sorting machine: such as sorting grade, removing device
100 product design, easy to edit and store
Fast product switching and automatic adjustment of the relative product sorting speed
USB large capacity storage, inspection records at any time access to
Intuitive and easy to use man-machine interface to reduce operator training time and cost
Technical parameter:
Weighing mode: strain resistance
Removing device: air injection / pneumatic arm / fall / pneumatic push rod (optional)
Operation mode: man-machine interface (7 inch /15 inch /10 inch optional)
Conveying speed: 100 m / min
Power supply: 50-60Hz AC110V/220V
Weight range: 3G-30KG
Accuracy: 0.2g
Speed: the fastest 180 pieces / min
Product size: within the length of less than 1M, width less than 0.6M
